The Protimeter Mini C is a pin type moisture meter that displays instant moisture content results on its 6 to 30% LED scale. The three-color coded LED scale gives the operator instant information regarding "Dry", "At Risk" or "Wet" conditions. All Protimeter instruments have a two-year warranty.
It is important that hardwood finish materials are in moisture equilibrium with the local indoor environment. The Mini C has this information printed right on the label. For example, a 70°F (20°C) environment with an average relative humidity of 60% would require a moisture content of approximately 11%.
The Mini C can also be used to make quick reference readings on concrete sub floors. These readings are surface, but allow th operator to quickly determine the moisture risk.
A range of optional extras are available, including pin extension probes and a hammer electrode for getting measurements up to 1-1/2" (38mm) below the surface.
|Display||LED bar graph with numerical display|
Auto shut off
|Warranty||24 months on mechanical or manufacturing defects. Does not include wearing part or accessories.|
|Packaging||Two replacement pin electrodes
Pin protection cap
Calibration check device
Calibration chart for 150 wood species
|Weight||Including batteries, 0.330 lb (150g)|
|Dimensions||7.02 in x 1.09 in x 1.91 in (180 mm x 28 mm x 49 mm)|
|Batteries||1 x 9V included|
|Mini C Moisture Meter Datasheet (English)|
|Calibration Table for Wood (English)|
|Calibration Table for Wood (Italian)|
Calibration Table for Wood (Dutch)
Calibration Table for Wood (Norwegian)
Calibration Table for Wood (German)
Calibration Table for Wood (Spanish)
Calibration Table for Wood (Swedish)
